频率(GHz) 14.0-14.5
IM3 (dBc) -
SCL Pout (dBm) -
P1dB (dBm) 41
G1dB (dB) 6
ηadd (%) 23
漏极电压VDS(V) 10
漏极电流(RF)(mA) 3600
Rth(°C/W) 1.8
应用 •50Ω internally matched•No external matching•Optimized for each frequency band
