频率(GHz) 14.0-14.5
IM3 (dBc) -46
SCL Pout (dBm) 26.5
P1dB (dBm) 37.5
G1dB (dB) 6.5
ηadd (%) 24
漏极电压VDS(V) 10
漏极电流(RF)(mA) 1800
Rth(°C/W) 4
应用 •50Ω internally matched•No external matching•Optimized for each frequency band
