频率(GHz) 8.5-9.6
IM3 (dBc) -45
SCL Pout (dBm) 29.5
P1dB (dBm) 40.5
G1dB (dB) 7.5
ηadd (%) 25
漏极电压VDS(V) 10
漏极电流(RF)(mA) 3600
Rth(°C/W) 2.3
应用 •50Ω internally matched•No external matching•Optimized for each frequency band
